Structure

Performance

ENGINE STARTING PERFORMANCE

ENDURANCE CHARACTERISTICS

SELF-DISCHARGE CHARACTERISTICS

WATER CONSUMPTION CHARACTERISTICS

Carefully read service manual before use the battery

Data Table

BATTERY
TYPE
CAPACITY
(Ah/5HR)
CHARGING
CURRENT
(A)
DIMENSIONS(mm) APPROX.
ACID
VOLUME
()
WEIGHT
ACID
(kg)
L W TH
40B19R 30 3 185 125 227 2.3 9.4
40B19L 30 3 185 125 227 2.3 9.4
46B24R 36 4 236 126 227 3.3 11.5
46B24L 36 4 236 126 227 3.3 11.5
55B24R 36 4 236 126 227 3.2 12.0
55B24L 36 4 236 126 227 3.2 12.0
55D23R 48 5 230 169 225 4.0 14.8
55D23L 48 5 230 169 225 4.0 14.8
75D23R 52 5 230 169 225 3.8 16.0
75D23L 52 5 230 169 225 3.8 16.0
80D26R 55 6 257 170 225 4.3 18.0
80D26L 55 6 257 170 225 4.3 18.0
95D31R 64 7 304 171 225 5.1 21.0
95D31L 64 7 304 171 225 5.1 21.0

Output Voltage・・・12V

TERMINAL POSITION

  • 40B19R
  • 46B24R
  • 55B24R
  • 55D23R
  • 75D23R
  • 80D26R
  • 95D31R
  • 40B19L
  • 46B24L
  • 55B24L
  • 55D23L
  • 75D23L
  • 80D26L
  • 95D31L
